Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation

Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation
Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation

Large Image :  Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation

Product Details:
Place of Origin: China
Brand Name: StepChina
Model Number: SS-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Wooden case
Delivery Time: 10-40 days
Supply Ability: 50 sets/year
Detailed Product Description
Standard Capacity: 1200-24000BPH Usage: Transportation Of Bottled Beverage
Frame: SUS 304 Driver: Electric Motor
Field: Package Power: 380V 50Hz 3 Phase
High Light:

belt conveyor systems

,

bottle conveyor belt

Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation



Quick Detail:

Name

bottled beverage conveyor, output conveyor, belt conveyor

Brand Name

StepChina

Capacity

1200-24000B/H

Material

Stainless steel 304

Function

bottle transportation

Usage

Connect filling machine to packing machines





Applications:

1. bottled beverage transportation.

2. connect filling machine to packing machines.





The product consists of holder, motor and conveying belt. It is used to connect filling machine with various packaging machines and convey bottled beverages to help finish packaging final products.



Technical Features:

1. Modular design: modular design is characterized by making products more diverse, simple and more changeable with other components, and install and maintenance convenient. According to specific requirements of users, different production capacity, and bottle shapes, it can also be combined into different conveying methods, module units, motors and control ways, thus this system enjoying high flexibility.

2. Stable and reliable conveying: The conveying belt and bottle protecting railing are equipped around turning and path-changing places at the size requirements of calculating. Then according to tests and theories, it can be calculated the change of velocity of every bottle belt, which increases or decreases in line with the progression of equal ratio. Finally, along with the synchronous control of bottle belt and main motor, it can achieve no overturning, no jamming, and no blocking while conveying, thus making bottles in conveying process no overturning, jamming and blocking.

3. Advanced and rational bottle conveying system controlled by electrical equipment: In order to successfully avoid bottle squeezing and blasting, controls between bottle belts, especially on high-speed conveying belt, adopt the mixture of coordinated and simple controls. The control components are approach switch, photoelectric tube, sensor and so on.

4. Various control methods: Users can figure out practical control way according to different requirements of graphic designs in order to achieve stable conveying. The electrical machine of bottle conveying belt are directly connected with bottle belt driving shaft, not using chain wheel conveying mode to transfer driving force as the traditional way. So the equipment enjoys compact structure and makes little noise. Besides, because of separate arrangement of electrical machine control box in line with specific graphic design, this device is quite convenient to operate.



Technical Parameters:

Production capacity (φ69 bottles as the standard):

0-24000BPH

Highest velocity of single-row bottle belt:

Vmax=65m/min

Applicable bottle shape:

Different kinds of standard PET bottles

Single bottle belt:

31.8Kg/m

Quantity of retraced single-row belt per meter:

10~20 Kg/m

Height:

1050±50mm





Competitive Advantage:

1. Stand bar and bottle hanging plate can be made of plastic and nylon materials. And other parts of this equipment are all made of stainless steel SUS304.

2. Every air inlet of fans is fitted with an air filter to prevent dusts from entering bottles. And a high efficiency air filter is equipped onto the last fan that is located in joint place of air conveying channel and filling machine.

3. An air cylinder is equipped at the end of bottle outputting, so users can prevent bottles in air conveying channel

from entering rinsing filling capping machine by manual control or by cooperation with filling machine.

Modular Stainless Steel Bottle Conveyor System For Bottled Beverage Transportation 0
